The main frame is composed of a sturdy steel structure, with the main colors being gray and yellow.
Equipped with a German Cyklop fully automatic high-frequency friction welding strapping head.
The strapping head has a moving stroke of up to 500mm, allowing it to better conform to the product surface.
The strapping head features a floating design, effectively balancing the tension on the four corners of the product, resulting in more balanced tension and more secure strapping.
Originating from the German modular design concept, the strapping head can be maintained from multiple directions when maintenance is required.
The strap channel is made of drawn aluminum alloy, with spring-loaded flaps on both sides, making strap feeding more convenient and efficient.
Equipped with a Chinese utility model patent sword-piercing device (Patent No.: ZL 2018 2 2007441.0), it completes actions such as sword piercing and strap feeding through a chain drive driven by a geared motor, which is efficient and durable. The equipped torque limiter ensures safe and reliable use.
The strap reel cart with brake facilitates quicker strap replacement and reasonable material supply.
Integrated electrical control cabinet design, more compact and space-saving.
The whole machine control system uses PLC and a color touch screen.
The control box is equipped with a cooling fan to better protect electrical components.
