Ampag CI 72

Ampag CI 72

The Ampag CI 72 is a versatile strapping machine. It handles medium-sized products efficiently while ensuring reliable, consistent strapping. Compact and user-friendly, it’s ideal for businesses that need both performance and flexibility. Stability.

The Cyklop Ampag CI 72 is a versatile strapping machine built for consistent performance in industrial production. It delivers up to 50 strappings per minute, providing both speed and reliability. The adjustable tension force from 0 to 500N, combined with a dual-power tension wheel system, ensures secure strapping for a variety of product sizes.
Compact in design with inner arch dimensions of W 650 x H 500 mm and a strap width range of 5 mm, 9 mm, or 12 mm (with corresponding thickness from 0.45 to 0.7 mm), the CI 72 accommodates medium-sized production capacity efficiently.

The machine is equipped with a P.C. Board control and intuitive touch panel, allowing operators to adjust strapping parameters quickly. Powered by a reliable DC motor with brush and operable via foot pedal, the Ampag CI 72 combines precision, ease of use, and industrial-grade durability.

It’s the perfect choice for businesses seeking efficient, secure, and adaptable strapping solutions.

Benefits:

•    Intuitive touch panel for fast adjustment
•    P.C. Board control simplifies operation
•    Foot pedal operation allows hands- free strapping
•    Straps up to 50 strappings per minute
•    Adjustable tension force up to 500N
•    Dual-power tension wheel system provides consistent results
•    Compatible with strap widths of 5, 9, 12 mm (0.45 - 0.7 mm thickness)
•     Accommodates a variety of carton sizes
•    Low-maintenance design ensures minimal downtime
•    High speed and high tension. Reliable for a wide range of cartons.

View full details
Technical Specification
Parameter Value
Strapping speed Max 50 strappings/min
Tension range Max 500N (adjustable)
Tensioning system 2 power wheels
Standard arch size inner W 650 x H 500 mm
Working table height 800 mm
Strap sizes width 5-6 mm
8-9 mm
11-12 mm
Strap thickness 0.45 - 0.7 mm
Strap coil Inner dia.: 200-210 mm
Outer dia.: 400-450 mm
Width: 170-190 mm
Control component P.C. board control
Control panel By touch panel
Power source 1P, 220-240V, 50Hz, 0.5kW
Brochures & Download Materials
Service Videos
Product Videos
More Information

Features:
• Faster adjustment and increased operator productivity with the intuitive touch panel
• Simplified controls reduce training time and errors
• Hands-free strapping boosts efficiency and ergonomics
• 50 strappings per minute increases productivity
• Adjustable and Consistent strap tension improves flexibility of product types and improves integrity
• Reliable performance ensures consistent results across diverse packaging needs
