Stretch Wrapper Cst 205 Auto

Name: Stretch Wrapper Cst 205 Auto
Brand: Cyklop
Availability: OutOfStock

What is CST 205 stretch wrapper?

CST 205 is an advanced pallet wrapping machine designed to streamline and automate packaging processes. Operators effortlessly load pallets onto the turntable and initiate the wrapping cycle using a remote control or touch panel. Once the cycle is complete, the machine autonomously cuts the film and ensures a clean finish by wiping the tail-end against the load. Notably, the film gripper keeps the film securely connected, ready for the next pack, while the entire wrapping cycle operates seamlessly in automatic mode, boosting productivity. Although pallet unloading remains a manual task, CST 205 boasts user-friendly controls for easy adjustment of program parameters and settings via its new display. This versatility extends to manual operation of various functions, such as film patterns and tension. Moreover, the machine maintains a consistent pre-stretch ratio, guaranteeing minimal film consumption and cost efficiency load after load.

Request a Quote

Not ready to buy yet? Talk to someone from our team

View full details

Technical Specification

Parameter	Value
Table diam	01650 mm 01650 mm
Speed	12rpm 12rpm
Capacity	10-25 pallets/hour (base on pallet height and turns to be wrapped)
Start/stop	Frequency controlled Frequency controlled
Bottom/Top wraps	1-9 1-9
Film carriage speed	Variable speed Variable speed
Pre stretch ratio.	250% and 200% manually, two-section variable (300% and 230% optional)
Stretch wrapping programs	8 adjustable 8 adjustable
Controller	PLC PLC
Power -	- -
Supply	Single phase 240 V 50 Hz Single phase 240 V 50 Hz
Loading	10A 10A
Pallet Goods -	- -
Max size (length/width)	1200X1000 mm 1200X1000 mm
Max goods height incl. pallet	2000 mm, Optional up to 3000 mm 2000 mm Optional up to 3000 mm
Permitted load weight	2000 kg 2000 kg
Stretch Film -	- -
Core diameter, max	76 mm 76 mm
Outer diameter, max	250 mm 250 mm
Film width, max	500 mm 500 mm
Film thickness	9-35 my (standard is 0.012~0.023mm 9-35 my (standard is 0.012~0.023mm
Auto-function -	- -
Auto gripper for film end mounting	YES YES
Constancy temperature heater for film end welding	YES YES
Cutting wire for film cutting	YES YES
Remote control	YES (3 Sets) YES (3 Sets)
